The electronic aid to safe reversing
and parking
Advanced Features
EPS4000-PRO BACK
Park Distance Control System (PDC)
EPS4000-PRO FRONT
Flush Mount Park Distance Control System (PDC)
Advanced Intelligence Dynamic Detection
Self-Learning of Sensor Positioning
Compatible with CAN-Bus vehicles
Compatible with vehicles with LED Lights
Self-Diagnosis ‘fault finding’
Sensitivity and Detection adjustment by Dip Switches
Provided with 3, 6 & 12 degree angled adaptors
Flush Fitting adaptor included
Paintable, with sensor head holder for easy painting
The EPS4000-PRO series is Sanji's most advanced sensor kits to date.
Changeable detection range and height where sensors need to be fitted low or detection occurs too early, making
the PRO a solution for most vehicles.
Self-learning sensitivity program function - after installation the ECU can be programmed automatically to detect the
height and positioning for better detection results with minimal false alarms. The ECU remembers the settings with
no need for additional programming.
Intuitive intelligence - the sensors learn each time they are activated if there are any stationary objects in the
detection zone. Tow bars can be added or taken away without the need for interference with the ECU. Dynamic
detection is also a key feature, and this enables the sensors to ignore objects that are moving away from the vehicle.
Advanced triangulation - the detecting zone of the sensors is squared off to ignore the far sides of the rear of the
vehicle, and this helps when parking in garages and alongside walls, traditional sensors do not account for this.
The kit includes flush fitting sensors and angle rings as standard for curved and low bumpers and 3M self-adhesive
pads, and black silicone seals. The angle rings range in inclination being 3, 6 and 12 degrees.
Advanced self-diagnosis will be audibly sound to advise if there is a fault with the product and provide details of any
faulty sensor.
The EPS4000-PRO-FRONT Parking Sensor System utilizes the most advanced ultrasonic asymmetrical sensing
technology. The sensor has ultra-wide detection capabilities that sense an extra-wide angle of 150 degrees
horizontally and 60 degrees vertically. This technology increases the detection angle by up to 100% compared
with other conventional systems.
Sanji has designed the micro-sized flush-mounted sensors to blend into all cars with a small size and
adaptability to curved plastic bumpers. The system can be used as a 2 or 4 sensor installation and is ideal for
any vehicle.
You can control the system with the accelerator pedal or brakes (fitment dependent). If an obstacle is
detected, the system will audibly warn the user for 3 seconds. If the obstruction remains moving, the audible
warning will stop. Pressing the brake pedal or reducing speed below 15kmph will activate the front sensors.
If there is no obstacle, the system will not warn or display an alert.
Specifications
Rated Voltage: 12 (DC V)
Operating Voltage: (9 ~ 16 DC V)
Operating Current: 150mA max.
Operating Temperature: -30 ~ 85
Storage Temperature: -40 ~ 85
Ambient Humidity: 90 RH max.
Protection Grade Sensor: IP67 / ECU: IP40
Specifications
Rated Voltage: 12 (DC V)
Operating Voltage: (9 ~ 16 DC V)
Operating Current: 150mA max.
Operating Temperature: -30 ~ 85
Storage Temperature: -40 ~ 85
Ambient Humidity: 90 RH max.
Protection Grade Sensor: IP67 / ECU: IP40
The electronic aid to
safe reversing and
parking
Advanced Features
Advanced Intelligence Dynamic Detection
Self-Learning of Sensor Positioning
Compatible with CAN-Bus vehicles
Compatible with vehicles with LED Lights
Self-Diagnosis ‘fault finding’
Sensitivity and Detection adjustment by Dip Switches
Provided with 3, 6 & 12 degree angled adaptors
Flush Fitting adaptor included
Paintable, with sensor head holder for easy painting
The EPS4000-PRO-FRONT Parking Sensor System
utilizes the most advanced ultrasonic asymmetrical
sensing technology. The sensor has ultra-wide
detection capabilities that sense an extra-wide
angle of 150 degrees horizontally and 60 degrees
vertically. This technology increases the detection
angle by up to 100% compared with other
conventional systems.
Sanji has designed the micro-sized flush-mounted
sensors to blend into all cars with a small size and
adaptability to curved plastic bumpers. The system
can be used as a 2 or 4 sensor installation and is
ideal for any vehicle.
You can control the system with the accelerator
pedal or brakes (fitment dependent). If an obstacle
is detected, the system will audibly warn the user
for 3 seconds. If the obstruction remains moving,
the audible warning will stop. Pressing the brake
pedal or reducing speed below 15kmph will activate
the front sensors.
If there is no obstacle, the system will not warn or
display an alert.
Specifications
Rated Voltage: 12 (DC V)
Operating Voltage: (9 ~ 16 DC V)
Operating Current: 150mA max.
Operating Temperature: -30 ~ 85
Storage Temperature: -40 ~ 85
Ambient Humidity: 90 RH max.
Protection Grade Sensor: IP67 / ECU: IP40
Specifications
Rated Voltage: 12 (DC V)
Operating Voltage: (9 ~ 16 DC V)
Operating Current: 150mA max.
Operating Temperature: -30 ~ 85
Storage Temperature: -40 ~ 85
Ambient Humidity: 90 RH max.
Protection Grade Sensor: IP67 / ECU: IP40
The EPS4000-PRO series is Sanji's most advanced
sensor kits to date.
Changeable detection range and height where
sensors need to be fitted low or detection occurs
too early, making the PRO a solution for most
vehicles.
Self-learning sensitivity program function - after
installation the ECU can be programmed
automatically to detect the height and
positioning for better detection results with
minimal false alarms. The ECU remembers the
settings with no need for additional
programming.
Intuitive intelligence - the sensors learn each
time they are activated if there are any stationary
objects in the detection zone. Tow bars can be
added or taken away without the need for
interference with the ECU. Dynamic detection is
also a key feature, and this enables the sensors
to ignore objects that are moving away from the
vehicle.
Advanced triangulation - the detecting zone of
the sensors is squared off to ignore the far sides
of the rear of the vehicle, and this helps when
parking in garages and alongside walls,
traditional sensors do not account for this.
The kit includes flush fitting sensors and angle
rings as standard for curved and low bumpers
and 3M self-adhesive pads, and black silicone
seals. The angle rings range in inclination being 3,
6 and 12 degrees.
Advanced self-diagnosis will be audibly sound to
advise if there is a fault with the product and
provide details of any faulty sensor.
